Oven

Description

Construction & Technical Features

Robust Triple-Walled Design

Engineered for durability and precision, the unit features a triple-walled construction ensuring maximum thermal efficiency and long service life.

• Inner Chamber: Crafted from high-grade Mild Steel or Stainless Steel (SS 304) for superior strength and corrosion resistance.
• Outer Body: Made of premium Mild Steel and finished with a high-quality epoxy powder coating, providing an elegant appearance and protection against environmental wear.
• Insulation: The inner and outer chambers are separated by a 75 mm thick layer of mineral wool insulation, effectively minimizing heat loss and maintaining consistent temperature performance.

Advanced Temperature Control

• Temperature range from 50°C to 300°C, maintained with an impressive accuracy of ±3°C.
• Integrated microprocessor-based digital temperature indicator-cum-controller with a bright LED display allows for precise temperature monitoring and user-friendly operation.

Efficient Heating System

• High-performance heating elements strategically placed on both sides of the chamber for rapid and uniform heat distribution.
• Designed to deliver optimal heating efficiency while ensuring long element life.

Precision Door Assembly

• The insulated door is equipped with high-quality asbestos rope or synthetic rubber gasket, ensuring an airtight seal to prevent heat leakage and maintain chamber stability.

Flexible Shelving Options

• Supplied with 2 or 3 removable Stainless Steel wire mesh shelves, allowing convenient arrangement and easy cleaning.

Uniform Air Circulation

• A powerful air circulating fan ensures even temperature distribution throughout the chamber, enhancing performance consistency and drying efficiency.

Power & Electricals

• Available in both 220/230V AC single-phase and 400/440V AC three-phase, 50 Hz configurations, ensuring compatibility with diverse operational requirements.
